This Fractal Audio Axe FX II with MC-101 Foot Controller is in EXCELLENT condition, with minimal wear and 100% perfect operation. All buttons, switches, indicators and jacks are in working with no issues. The original power supply and associated cable for the MC-101 are in included as well as the pre-installed Mission Engineering Stomp Plates.
This FRACTAL AUDIO AXE FX II with MC-101 Foot Controllers is brought to you by BCR Music & Sound, Central PA's premier guitar, amp, and pedal dealer! The photos in this listing are of the actual instrument for sale here in our store.
Description:
A complete rackmounted system for guitar amplification modeling and effects, the Fractal Audio Axe FX II improves on the acclaimed original by providing even better sound, more presets and more flexibility than ever. Two state-of-the-art Analog Devices TigerSHARC DSPs are onboard, one dedicated solely to amp modeling, the other for effects. Every nuance of the gear modeled is painstakingly maintained, which is why the Fractal Axe FX II is one of the most popular and award winning pieces of modeling gear in guitar history.
Axe-Fx II Specifications:
FRONT PANEL INPUT
Connector: 1/4” phone jack, unbalanced.
Impedance: 1 MegaOhm (less if Input Impedance is active)
Max. Input Level: +16 dBu (conditioned for guitar use)
REAR INPUTS
Connector: 1/4” phone jack, balanced.
Impedance: 1 MegaOhm
Max. Input Level: +20 dBu
A/D CONVERSION
Bit Depth: 24 bits
Sample Rate: 48 kHz
Dynamic Range: > 110 dB
Frequency Response: 20 – 20kHz, +0 / -1 dB
Crosstalk: < -60 dB over full bandwidth
ANALOG OUTPUTS
Connectors: 1/4” phone jack unbalanced (hum-canceling), XLR balanced (for main output)
Impedance: 600 ohm
Max Output Level: +20 dBu
Dynamic Range: > 110 dB
Frequency Response: 20 – 20kHz, +0 / -1 dB
Crosstalk: < -60 dB over full bandwidth
DIGITAL I/O
Connectors: RCA Coaxial Type for S/PDIF I/O, XLR for AES I/O
Format: S/PDIF – 24 bit
Sample Rate: 48 kHz fixed
USB Audio Clock 48 kHz fixed
MIDI INTERFACE
Input Connector: 7-pin DIN (pins 6 & 7 connected to phantom power in jack)
Out/Thru Connector: 5-pin DIN
PEDAL INTERFACE
Connector: 1/4” TRS phone jack
Format: Switch: Momentary or Latching; Pedal: 10–100kΩ max, linear taper expression type.
MFC INTERFACE:
Connector: RJ-45 Ethernet/EtherCON
IMPORTANT: Do NOT connect the MFC port to a computer or router/switch/hub!
This jack is only intended for connection to an MFC MIDI Foot Controller.
PHANTOM POWER:
Connector: Female 2.5mm jack
WARNING: Do NOT connect adapters with a rating higher than 1A (1000ma)
GENERAL
Finish: Powder coated steel chassis with anodized aluminum faceplate
Display: 160 × 80 dot matrix graphic LCD
Dimensions: 19” × 3.5” × 14.25” (483 × 88 × 362 mm)
Weight: 14.75 lbs (6.7 kg)
Input Voltage: 100–240 VAC, 47 – 63 Hz (universal input)
Power Consumption: <40 W
Backup Battery Life: >10 years
Backup Battery Type: CR2450 Lithium
ENVIRONMENTAL
Operating Temperature: 32 to 122 °F (0 to 50 °C)
Storage Temperature: -22 to 167 °F (-30 to 70 °C)
Humidity: Max. 90% non-condensing
We'll double-inspect and play-test, professionally pack with care, and ship this instrument within 1 business day, and most cases, the same day if the order is placed by 3pm EST.
